FELK engineers design our boat trailers for real world use. We get that they’re going to be exposed to salt. We understand you want to minimise body-roll when driving your boat around. We make our trailers to last decades, not years.

Please note we offer trailer fitting as an additional service. This improves the balance of the trailer, and is an important consideration to maximise road safety. Please scroll below to view pricing.

Aluminium Boat Trailers

FELK Engineering can design and manufacture trailers for inboards, any trailerable yacht, or we can custom design a trailer to your specific needs.
Note: Electric hydraulic brakes come with a safety breakaway unit made and serviced in Australia.

  • Australian Marine Grade Aluminium
  • NEW galvanised steel rims, NEW light truck tyres
  • Black Plastic Guards
  • 7 pin flat electrical plug
  • Galvanised axle
  • Webbing winch
  • Swivel bracket Jockey wheel
  • Built to RMS specifications
  • LED submersible lights
  • 3 year Limited back to base warranty

Aluminium Boat Trailer Pricing

On mobile phones, please slide to the right to view the entire table below –

MODEL # SUITS BOATS UP TO WHEELS (inch) BRAKE TYPE NUMBER OF AXLES TARE (kg) ATM (kg) PRICE
BTRA2114T3 7.0m  (23′) 14″ Elec Hyd 2 500 3000 $12,010.20

All prices include 10% GST. Registration is not included. ** Prices are current as at 10th Feb 2020 and are subject to change without notice **
FELK Engineering can provide full in house registration services.

Multiroller Boat Trailers

Electric hydraulic brakes come with a safety breakaway unit made and serviced in Australia.
(Fitting is free at time of trailer purchase).

  • Hot dipped galvanised using Australian steel
  • NEW galvanised steel rims, NEW light truck tyres
  • Black Plastic Guards
  • 7 pin flat electrical plug
  • Galvanised axle
  • Webbing winch
  • Swivel bracket Jockey wheel
  • Built to RMS specifications
  • LED submersible lights
  • 3 year Limited back to base warranty

Multiroller Boat Trailer Pricing

On mobile phones, please slide to the right to view the entire table below –

MODEL # SUITS BOATS UP TO WHEELS BRAKE TYPE NUMBER OF AXELS TARE (kg) ATM (kg) PRICE
BTR1210DLX 3.8m (12′) 10″ N/A 1 100 500 $1,700
BTR1310DLX 4.1m (13′) 10″ N/A 1 120 600 $2,100
BTR1313DLX 4.1m (13′) 13″ N/A 1 120 600 $2,200
BTR14/1513 4.7m (14-15′) 13″ N/A 1 160 750 $2,888
BTR14/1513B 4.7m (14-15′) 13″ Mech Disc 1 200 1000 $3,471
BTR16/1713 5.3m (16-17′) 13″ N/A 1 200 750 $3,424
BTR16/1713B 5.3m (16-17′) 13″ Mech Disc 1 240 1000 $4,006
BTR16/1714T1.4 5.3m (16-17′) 14″ Mech Disc 1 250 1400 $4,246
BTR16/1713T2 5.3m (16-17′) 13″ Mech Disc 2 280 2000 $5,040
BTR16/1714T3 5.3m (16-17′) 14″ Elec Hyd 2 540 3000 $8,186
BTR1813B 5.8m (18′) 13″ Mech Disc 1 280 1000 $5,302
BTR1814T1.4 5.8m (18′) 14″ Mech Disc 1 300 1400 $5,805
BTR1813T2 5.8m (18′) 13″ Mech Disc 2 380 2000 $6,335
BTR1814T3 5.8m (18′) 14″ Elec Hyd 2 540 3000 $9,112
BTR1913B 6.1m (19′) 13″ Mech Disc 1 280 1000 $5,572
BTR1914T1.4 6.1m (19′) 14″ Mech Disc 1 300 1400 $5,810
BTR1913T2 6.1m (19′) 13″ Mech Disc 2 400 2000 $6,604
BTR1914T3 6.1m (19′) 14″ Elec Hyd 2 560 3000 $9,382
BTR2114T2 7m (21′) 14″ Mech Disc 2 440 2000 $7,909
BTR2114T3 7m (21′) 14″ Elec Hyd 2 640 3000 $10,690
BTR2115T3.5 7m (21′) 15″ Elec Hyd 2 760 3500 $11,845
BTR2115T4 7m (21′) 15″ Elec Hyd 2 720 4000 $12,195
BTR2514T3 7.9m (25′) 15″ Elec Hyd 2 3000 $13,149
BTR2514T4 7.9m (25′) 14″ Elec Hyd 2 680 4000 $13,967
BTR2515T4 C 7.9m (25′) 15″ Elec Hyd 2 4000 $14,062
BTR2514T4.5 7.9m (25′) 14″ Elec Hyd 2 740 4500 $18,550
BTR2515T4.5 C 7.9m (25′) 15″ Elec Hyd 2 4500 $18,645

All prices include 10% GST. Registration is not included. ** Prices are current as at 10th Feb 2020 and are subject to change without notice ** FELK Engineering can provide full in house registration services.

Skid Boat Trailers

A range of skid trailers 14-17′ are available on request. Fitting fee at time of trailer purchase.

  • Hot dipped galvanised using Australian steel
  • NEW galvanised steel rims, NEW light truck tyres
  • Black Plastic Guards
  • 7 pin flat electrical plug
  • Galvanised axle
  • Webbing winch
  • Swivel bracket Jockey wheel
  • Built to RMS specifications
  • LED submersible lights
  • 3 year Limited back to base warranty

Skid Trailer Pricing

On mobile phones, please slide to the right to view the entire table below –

MODEL # SUITS BOATS UP TO WHEELS BRAKE TYPE NUMBER OF AXELS TARE (kg) ATM (kg) PRICE
BTS1210DLX 3.7m (12′) 10″ N/A 1 100 500 $1,900
BTS1310DLX 4.1m (13′) 10″ N/A 1 120 600 $2,300
BTS1313DLX 4.1m (13′) 13″ N/A 1 120 600 $2,400

Trailer Fitting

Trailer fitting is the process of customising a trailer’s adjustable mechanisms (listed below) to suit an individual boat. Overall, this will improve the balance of the payload and remove trailer sway.

Trailer sway is the side-to-side movement of a trailer that happens when a force, such as strong wind, impacts the trailer at a perpendicular angle.

Not all trailer engineers offer this service, however at FELK, road safety is our priority. We encourage our clients who are aiming for maximum safe performance to consider this service. If you have any questions, please contact us.

  • Adjusted tow ball weight
  • Adjusted rollers
  • Adjusted axels
  • Adjusted bow post

Boat Fitting & Extras Pricing

FITTING SERVICE PRICE
FIT 12-13′ BOAT TO TRAILER $75
FIT 14-17′ BOAT TO TRAILER $175
FIT 18-19′ BOAT TO TRAILER $295
FIT 20-25′ BOAT TO TRAILER $495
ADDITIONAL EXTRAS
WALKWAY $395
GUIDE POST W/U BOLTS (each) $190
SKIDS IN LIEU OF ROLLERS (14-17) $200
HINGED SWINGAWAY DRAWBAR $500

Trailer fitting (non FELK models)

Felk Engineering are able to perform a boat fitting service for non-Felk trailers.

The point of difference is, that we cannot offer fixed pricing on this service as we are not familiar with other manufacturers designs, parts and ideal settings. This is something that can be determined in person at our Warners Bay workshop (a free quote will be provided).

The process remains the same as our regular boat fitting listed above.

Second hand trailers are usually more expensive to adjust due to seized and rusted parts – or worn out parts.

Slipway Trolley Trailers

Our Slipway Trolley trailers are blue-label products, suitable for those with boat ramps at their property

Learn more about Slipway Trolley Trailers.

Catamaran Trailers

Exceptional quality catamaran trailers, customised to your setup.

Learn more about Catamaran Trailers.



Boat Trailer FAQ

  • Do salt and rust have an effect on the trailer, and what steps should I take to care for it?

    Rust will jeopardise the structural integrity of a trailer.

    Exposure to a salty environment will start the process of electrolysis which will slowly break down the protective galvanised coating. Once this coating is depleted, the steel structure will rapidly rust. Rust will most commonly start from inside the RHS (box steel) chassis where the saltwater cannot be hosed off.

    To prevent problems with rust, we recommend clients always wash their trailer with fresh water (not soapy) as thoroughly as possible after every use.

    FELK engineers understand our boat trailers will be exposed to high levels of salt, particularly between the beaches of Newcastle and the shores of Lake Macquarie.

    The average lifespan of a trailer exposed to regular use in saltwater is 15 years providing it has been well maintained.
    FELK Engineers will check for signs of rust during your service and e-safety inspection. It is always important to be vigilant of this potential rust problem.

  • How regularly should I get my boat trailer serviced?

    As a rule of thumb, we recommend clients have their trailer(s) serviced every 12 months or before every long trip. This period may be longer or shorter depending on the frequency of use. Wheel bearings are a major consideration. I’m sure you have seen many a trailer broken down on the side of a road with a wheel off on a hot summer’s day. That’s a wheel bearing problem!

  • How do I select the right model for my boat?

    We would encourage you to get in touch with the FELK team. We’ll ask questions about your boat make, model, year, current loaded weight on the existing trailer. With this information, we will match the right trailer to your requirements.

  • If well maintained, how many years of service should I expect from my FELK boat trailer?

    FELK boat trailers that are well maintained usually average a lifespan of 15 years.

  • What tyre pressure should I use for my boat trailer tyres?

    Approximately 45 PSI is the average pressure required for the weight of the loaded boat and the capacity of the light truck tyres.

  • Can FELK Engineers convert skids to rollers?

    Yes, though it depends on the type, make and model of the trailer.

  • How do I know if I need a multi-roller or a skid trailer?

    Multi-roller trailers are much more popular than skid. Around 95% of our sales use multi-rollers. Skid trailers are becoming far less common.

    With multi-roller setups, you don’t need to submerge the trailer as deep in the water compared to a skid trailer. The rollers allow the craft to move freely once the winch is disconnected, making launch and retrieval easier.

    Multi-rollers will give your hull better support with equal pressure on all the rollers. Most yacht trailers are now converting to multi-roller systems for this reason.

    Some people may still opt for a skid trailer if their hull is comprised of thin alloy hull or plywood eg. an old ski boat.
